Chauvet Pro COLORdash Par-Hex 12XIP - IP Rated RGBWA-UV LED Wash Light

Code: CHAPROCOLORDASHPARH12XIP

Get the ultimate all-weather RGBWA-UV LED wash light. IP-rated, flicker-free on camera, with smooth dimming & touchscreen control for pro events.






Please call us on +353 (0)74 91 45179 for a price.
Or Email info@ror.ie for more information.
Chauvet Pro COLORdash Par-Hex 12XIP - IP Rated RGBWA-UV LED Wash Light

Engineered for the demands of modern event production, this rugged RGBWA-UV LED Wash is the ultimate lighting tool for any environment. Its robust, IP-rated chassis and weatherproof connections provide complete peace of mind, delivering flawless performance whether used for indoor galas or exposed to the elements at outdoor festivals. This fixture is built to be a reliable workhorse in any professional lighting rig.

Beyond its durable construction, this wash light delivers exceptional visual performance. Advanced optics ensure outstanding colour mixing and high efficiency from its 6-in-1 LEDs, capable of producing a vast spectrum from rich, saturated colours and subtle pastels to a true UV blacklight effect. Designed for the broadcast era, it features adjustable PWM and selectable dimming curves to eliminate on-camera flicker and ensure perfectly smooth fades, making it an essential fixture for any event being filmed or streamed.

Key Features:
  • All-Weather Versatility: A rugged design with IP-rated power and DMX connections ensures reliable operation for both indoor and outdoor events, regardless of weather conditions.
  • Flicker-Free On Camera: Adjustable PWM (Pulse Width Modulation) guarantees a flicker-free output, making it perfect for broadcast, live streaming, and film applications.
  • Superior Colour Mixing: Advanced optics and high-efficiency 6-in-1 (Red, Green, Blue, White, Amber, UV) LEDs produce an exceptionally wide colour palette and brilliant UV effects.
  • Flawless Dimming Performance: Selectable, smooth dimming curves eliminate flickering and choppiness, providing seamless and professional-looking fades.
  • Intuitive Interface: An easy-to-read OLED display with a password-protected touchscreen interface allows for quick and secure adjustments.
  • Remote Device Management (RDM): Offers enhanced flexibility for remote addressing and troubleshooting, saving valuable time during setup and operation.
  • Flexible Mounting Options: The double-bracketed yoke, complete with an included omega bracket, allows for easy truss mounting and also serves as a sturdy floor stand for uplighting applications.
Optical
  • Light Source: 12 LEDs (hex-color RGBAW+UV) 120 W, (512 mA), 50,000 hours life expectancy
  • Color Temperature (range): 2800 to 10,000 K
  • Color Temperature (at full): 11,008 K
  • Beam Angle: 22.2°
  • Field Angle: 36.9°
  • Lumens: 4,532
  • Illuminance (total): 1,052 lux @ 5 m
  • Selectable PWM: 600, 1.2k, 2k, 4k, 6k, 25k Hz

Dynamic Effects
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Strobe Rate: 0 to 20 Hz
  • Standalone Color Mixing: Yes
  • Color Temperature Presets: Yes
  • Dim Modes: 4
  • Built-in Automated Programs: Yes

Construction / Physical
  • Dimensions: 9.1 x 12 x 9.8 in (232 x 305.4 x 247.9 mm)
  • Weight: 11.8 lbs (5.4 kg)
  • Exterior Color: Black
  • Housing Material: Aluminum alloy, Aluminum die-cast
  • Accessory Holder/Gel Frame Size: 8.75 in (222 mm)

Connections
  • Power Connection: Edison (Local) plug to Seetronic Powercon IP65
  • Power Output: Seetronic Powercon IP65
  • Data Connectors: 3 and 5-pin IP65 XLR
  • Cable Length (power): 5 ft (1.5 m)

Control
  • Control Protocol: DMX, RDM
  • DMX Channels: 6ch ,8ch ,9ch ,13ch, or 14ch
  • Modes/Personalities: 5 personalities (6ch ,8ch ,9ch ,13ch, or 14ch)

Electrical
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: 11 units @ 120 V; 19 units @ 208 V; 21 units @ 230 V
  • Power and Current: 126 W, 1.041 A @ 120 V, 60 Hz
  • Power and Current: 123 W, 0.604 A @ 208 V, 60 Hz
  • Power and Current: 123 W, 0.547 A @ 230 V, 50 Hz

Certifications / Qualifications
  • CE, MET, FCC, UKCA
  • IP Rating: IP65, temporary outdoor/wet use
  • Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

What's Included
  • Colordash Par H12XIP
  • Seetronic powercon IP65 power cord
  • Gel frame holder (8.75 in/222 mm accessories)
  • Omega bracket

Optional Accessories
  • Professional Clamps: CTC-50HC, CTC-50HCN
  • Seetronic Powercon power linking cables
  • 5-pin IP or Non-IP DMX Cables
